Electric actuators for industry and offshore for
90° rotation movement with torques of between 5 Nm and 15 Nm for
adjusting:
Ventilation dampers
Throttle valves
Closing time < 1 sec.
High efficiency
Integrated heating system guarantees operation up to -40° C with rated
torques
Non-loaded spring return with guaranteed service life of 5000 cycles
External function test using switch
Four adjustable run times, adjustable externally without tools using
switch
External display of operating states using coloured LEDs
Internal storage of operating states, readable by the manufacturer
UNIVERSAL SAFETY MOTOR -ELITE
90° Quarter turn actuators for safe area
5 - 30 Nm
Protection class IP66
Not Explosion proof
30 - 150 Nm
15 -30 Nm
Additional
info
Datasheet
Datasheet
These actuators are a revolution for safety,
control and shut-off dampers, VAV systems, ball valves, throttle valves
and other motorized applications for HVAC systems, in chemical,
pharmaceutical, industrial and Offshore-/Onshore plants.
IP66 protection, small dimensions, only 3,5 kg
weight, universal functions and technical data, an integrated heater and
an optional stainless steel housing guarantee safe operation even under
difficult environmental conditions. High quality brushless motors
guarantee long life.
All actuators are programmable and adjustable on
site. Special tools or equipment are not required. 5 motor running times
and 2 torques as well as 2 spring return times, according to the
actuator type, are selectable or adjustable on site. The integrated
universal power supply is self adaptable to input voltages in the range
of 24 to 240 VAC / DC.
The actuators are 100% overload protected.
The F-actuators are equipped with spring return
fail safe function.
Standard shaft connection is a squared direct
coupling with 12 × 12 mm.
Different accessories are available to adapt aux.
switches, terminal boxes or adaptations for ball valves and throttle
valves.
Features
Industrial actuator
Universal supply unit from 24 to 240 VAC/DC
5 different motor running times (3-15-30-60-120
s/90°), adjustable on site
2 different spring return running times (3-10
s/90°), selectable on site
On-off and 3-pos. control with or without
spring return function
100 % overload protected
Self-locking up to 15 Nm
Compact design and small dimension (L × W × H =
210 × 95 × 80 mm)
Direct coupling to the damper shaft with
squared connection 12 × 12 mm
95° angle of rotation incl. 5° pretension
Robust aluminium housing (optional stainless
steel or Amercoat painting)
IP66 protection
Simple manual override include + preparation
for comfortable manual override
Gear made of stainless steel and sinter metal
Weight only ~ 3.5 kg
Integral heater for ambient temperatures down
to
−40°C
Integral safety temperature sensor
Integral equipment for manual adjustment (push
button, lamp, switch)
Preparation for adaptable aux. switches type
InSwitch
Range of accessories
90° Quarter turn actuators for safe area
30 - 150 Nm
Protection class IP66
Not Explosion proof, for industrial applications
These actuators are a revolution for safety,
control and shut-off dampers, ball valves, throttle valves and other
motorized applications for HVAC systems, in chemical, pharmaceutical,
industrial and Offshore-
/Onshore plants, for use in Ex-areas zone 1, 2
(gas) and zone 21, 22 (dust).
Highest protection class (ATEX) and IP 66
protection, small dimensions, only 9,5 kg weight, universal functions
and technical data, an integrated heater guarantee safe operation even
under difficult environmental conditions. High quality brushless motors
guarantee long life.
All actuators are programmable and adjustable on
site. Special tools or equipment are not required. Motor running times
and torques - according to the actuator type - selectable or adjustable
on site. The integrated universal power supply is self adaptable to
input voltages in the range of 24 to 240 VAC/DC.
The actuators are 100% overload protected.
The...-F
actuators are equipped with spring return
fail safe function Standard shaft connection is a double squared direct
coupling with 16 × 16 mm.
Different accessories are available to adapt aux.
switches, terminal boxes or adaptations for ball valves and throttle
valves.
Industrial actuators
Universal supply unit from 24 to 240 VAC/DC
5 different motor running times
(40-60-90-120-150 sec./90°), adjustable on site
Spring return fail safe operation in ~ 20 sec.
On, Off, 3-pos, with or without spring return
function
30 - 150 Nm actuators in the same size (M)
100% overload protected
Compact design and small dimension (L × W × H =
286 × 150 × 116 mm)
Direct coupling to the damper shaft with
squared connection 16 × 16 mm
95° Angle of rotation incl. 5° pre-tention
Robust aluminium housing with IP66 protection
Simple manual override include + preparation
for comfortable manual override
Gear made of stainless steel and sinter metal
Weight only ~ 9.5 kg
Integral heater for ambient temperatures down
to -40°C
Integral safety temperature sensor
Integral equipment for manual adjustment (push
button, lamp, switch)
Preparation for adaptable aux. switches type
InSwitch
